Bell Pendant Light
The Casablanca Leuchten design classic. The AIH series captivates due to its timeless modern shape of the elaborately handblown glass shade from our traditional glass blowing workshop.
The high-quality opal glass in white-matt, white-glossy, cream-matt or cream-glossy creates a comfortable soft room light.
Casablanca Leuchten GmbH
Max-Planck-Straße 16, 63303 Dreieich | +49 (0)6103 803770 | info@casablanca.de
The Casablanca Leuchten design classic. The AIH series captivates due to its timeless modern shape of the elaborately handblown glass shade from our traditional glass blowing workshop.
The high-quality opal glass in white-matt, white-glossy, cream-matt or cream-glossy creates a comfortable soft room light.
Specifications
Additional InformationReplaceable Light Source
Light Fixtures Made to Last
For an above-average product lifetime and for the sake of the environment, we design and manufacture our luminaires in such a way that the light source and, if present, the driver are always replaceable. For this reason, our luminaire models either use sockets that can be fitted with commercially available LED light sources or they use LED light source that can be replaced by a qualified electrician or by us. We follow market standards so that the LED light sources we use will still be available in comparable designs in the future. In this way, we ensure that our customers can enjoy a Casablanca luminaire for a long time and that the environment is protected by avoiding electrical waste.
EPREL
European Product Registry for Energy Labelling
The EU energy labelling and ecodesign legislation help improve the energy efficiency of products on the EU market.
Ecodesign sets common EU wide minimum standards to eliminate the least performing products from the market. The energy labels provide a clear and simple indication of the energy efficiency and other key features of products at the point of purchase. This makes it easier for consumers to save money on their household energy bills and contribute to reducing greenhouse gas emissions across the EU.
The EU legislation for energy labels and ecodesign has been estimated to bring energy savings of approximately 230 Mtoe (million tonnes of oil equivalent) by 2030. For consumers, this means an average saving of up to €285 per year on their household energy bills. Moreover, energy efficiency measures will create €66 billion in extra revenue for European companies.
Suspension Types
Wire Pendant Luminaire Information
Fixture can be suspensed with either the electrical cable or a Holding Wire
Longer Suspension
Casablanca pendant luminaires are supplied with suspensions for an average room height of 2.50 to 2.85 meters. The suspensions can be shortened. For higher ceilings, the luminaires can be ordered with longer suspensions.
Multiple Suspension
The double pendant allows individual positioning of the two pendants in the desired distance between from each other. Also available as „rise&fall“ suspension.
For multiple fixture mounting please place an order for an additional single pendant WITHOUT CEILING CANOPY.Multiple Fixture
Oblique Ceilings
Casablanca luminaires can be adapted and extended with optional accessories to structural conditions and individual requirements.
Pendant luminaires cannot be mounted on sloping ceilings without modifications, otherwise there is a risk of the mounting brackets coming loose or the wire getting damaged. This is why Casablanca offers special accessories for mounting on sloping ceilings.
Rise & Fall Suspension
Casablanca luminaires can be adapted and extended with optional accessories to structural conditions and individual requirements.
Single Pendant with »Rise & Rall« Suspension (two fixing possibilities)
Ceiling Fixture
Wire Pendant Luminaire Information
In case the electric outlet isn’t located where the luminaire is planned to be installed, we recommend the decentralized fixing possibility. Longer electric cables or holding wires are available for a surcharge.
Central fixing possibility
Decentralised fixing possibility
Material
- Standard
Metal
Black
White
- White Option
Blue
Pantone 666 C
Varient
AIH 19 Single Pendant
- A: 19cm
- B: 10cm
- C: 0-150cm
- D: 9cm
- 1x G9 Halopin (60W Max - Not Included)
- Standard Cable Supplied Cable Length 250CM
| Color | Model |
|---|---|
| white matt | AI51-B78A |
| glossy white | AI41-B78A |
| glossy cream | AI47-B78A |
AIH 28 Single Pendant
- A: 28cm
- B: 17cm
- C: 0-150cm
- D: 9cm
- 1x E27 75W max - not included
- Standard Cable Supplied Cable Length 250CM
| Color | Model |
|---|---|
| white matt | AI01-B77A |
| glossy white | AI21-B77A |
| cream matt | AI07-B77A |
| glossy cream | AI21-B77A |
AIH 39 Single Pendant
- A: 38cm
- B: 20cm
- C: 0-150cm
- D: 9cm
- 1x E27 (105W Max - Not Included)
- Standard Cable Supplied Cable Length 250CM
| Color | Model |
|---|---|
| white matt | AI11-B77A |
| glossy white | AI31-B77A |
| cream matt | AI17-B77A |
| glossy cream | AI37-B77A |
